Common Mode Choke Noise Suppression Solution

Common Mode Chokes
January 22, 2026
Category Connection: Common Mode Chokes
Chat Now Contact Us
Tags:
#Common Mode Chokes #Filter Choke Inductor #Common Mode Power Line Choke
Brief: This short presentation tells the story behind the design and its intended use cases. Discover how our Common Mode Chokes provide effective noise suppression solutions for industrial, automotive, medical, and communication applications. Watch as we demonstrate the compact 3216 and 1608 SMD sizes in action, showcasing their role in systems requiring reliable EMI filtering and signal integrity.
Related Product Features:
  • Available in two compact SMD sizes: 3216 (3.2x1.6x1.8mm) and 1608 (1.6x0.85x1.1mm) for various space requirements.
  • High common mode impedance at high frequencies delivers excellent noise suppression performance.
  • Impedance range from 20Ω to 2000Ω allows selection for different noise levels and signal frequencies.
  • Suitable for diverse applications including industrial control, automotive electronics, and medical equipment.
  • Designed for IEEE 1394 lines in personal computers, DVC, and STB systems.
  • Comprehensive EMC support services including component selection, simulation, and testing.
  • Certified with ROHS, SGS, and ISO standards ensuring quality and compliance.
  • Reliable delivery within 1-3 weeks with flexible payment terms available.
FAQs:
  • What are the available sizes for these Common Mode Chokes?
    We offer two SMD sizes: 3216 measuring 3.2mm x 1.6mm x 1.8mm and 1608 measuring 1.6mm x 0.85mm x 1.1mm, catering to different space constraints and application needs.
  • What impedance options are available for noise suppression?
    Our Common Mode Chokes offer impedance values ranging from 20Ω to 2000Ω, allowing you to select the optimal specification based on your specific noise level and signal frequency requirements.
  • What certifications do these Common Mode Chokes hold?
    Our chokes are certified with ROHS, SGS, and ISO standards, ensuring they meet international quality and environmental compliance requirements for reliable performance.
  • What EMC support services do you provide with these components?
    We offer comprehensive EMC support including component selection guidance, simulation services, training programs, and rectification and testing services to help optimize your system's electromagnetic compatibility.
